解决Flutter分享微信小程序图片清晰度问题

背景：最近做flutter项目，做微信分享小程序，小程序卡片图片很模糊，经过排查确定了问题以及解决方法，排查思路记录一下。分享微信所用的flutter插件是fluwx^4.4.9

刚开始用的是Canvas画布绘制，思考，如果是画布的话出现图片模糊一般是绘制图片的画布比较小，而显示比较大，图片从小放大，会导致图片模糊，且画布绘图比较繁琐。经过调整保存本地发现图片清晰度有提升但未达到理想清晰度
转变思路，Flutter自带快照控件RepaintBoundary，思路是通过将要截图的Widget通过Stack放在主页面之下，然后执行快照。得到的图片清晰度很高
最终两个方案采用第二种得到了理想的清晰度图片，并且保存到相册核查，清晰度很好了，然后开开心心的去分享去，fluwx代码：

  // 微信分享初始化插件
  Fluwx fluwx = Fluwx();
  state.fluwx.registerApi(
      appId: "你的微信开放平台对应项目的APPID",
      doOnAndroid: true,
      doOnIOS: true,
      universalLink: "苹果端universalLink地址",
    );
   // 分享部分代码：WeChatImage有四种模式：network、asset、file、binary
    WeChatShareMiniProgramModel model = WeChatShareMiniProgramModel(
      //原始id（gh_5e56a391f33c）不是appid（wxe0338d0acbe46db9）
      userName: "小程序ID",
      webPageUrl: "${state.url}",
      path: "小程序提供地址，在这里给小程序传参也在这里",
      title: "小程序标题",
      miniProgramType: WXMiniProgramType.release,
      compressThumbnail: Platform.isAndroid ? false : true,// 图片是否压缩
      thumbnail: WeChatImage.binary(state.shareToWeChatImageSource!),
      hdImagePath: WeChatImage.binary(state.shareToWeChatImageSource!),
    );
    state.fluwx.share(model);

同时这里也贴一下生成快照的代码

// 保存相册方法
  Future savePhoto(BuildContext context, GlobalKey key,
      {bool shareToWechat = false}) async {
    showDialog(
        context: context,
        useRootNavigator: true,
        barrierDismissible: false,
        builder: (buildContext) {
          state.dialogContext = buildContext;
          return LoadingDialog(
            outsideDismiss: false,
            loadingText: '正在生成...',
          );
        });
    var photosStatus = await Permission.photos.request();
    var storageStatus = await Permission.storage.request();
    RenderRepaintBoundary? boundary =
        key.currentContext!.findRenderObject() as RenderRepaintBoundary?;
    double dpr = MediaQuery.of(context).devicePixelRatio; // 获取当前设备的像素比
    ui.Image image = await boundary!.toImage(pixelRatio: dpr);
    // 将image转化成byte
    ByteData? byteData = await image.toByteData(format: ImageByteFormat.png);
    Uint8List pngBytes = byteData!.buffer.asUint8List();
    if (shareToWechat == false) {
      if (photosStatus.isGranted == true ||
          (storageStatus.isGranted == true && Platform.isAndroid)) {
        Map result = await ImageGallerySaver.saveImage(pngBytes, quality: 100);
        bool isSaveSuccess = result['isSuccess'];
        dismissLoading();
        if (isSaveSuccess) {
          MyCommonUtils.showToast("保存成功！");
        } else {
          MyCommonUtils.showToast("保存失败！");
        }
      } else {
        dismissLoading();
        MyCommonUtils.showToast("请打开设置打开保存相册的权限~");
        openAppSettings();
      }
    } else {
      if (Platform.isIOS) {
        state.shareToWeChatImageSource = pngBytes;
      } else {
        Directory documentsDir = await getApplicationDocumentsDirectory();
        Directory directory = Directory('${documentsDir.path}/flutter');
        if (!directory.existsSync()) {
          directory.createSync();
        }
        const filename = 'fenxiang.png';
        File file = File('${directory.path}/$filename')
          ..createSync(recursive: true)
          ..writeAsBytesSync(pngBytes);
        Uint8List? pngBytes1 = await FlutterImageCompress.compressWithFile(
          file.absolute.path,
          minWidth: image.width,
          minHeight: image.height,
          quality: 30,
        );
        print('=========长度${pngBytes1?.length}');
        state.shareToWeChatImageSource = pngBytes1;
      }
      dismissLoading();
    }
  }
